Download PCB/PCBA and Wire Harness Starter Documents
If you're submitting a wire harness project, just reach out — our team will guide you through the quoting and build process for those assemblies as well.
How to Submit Your First PCB/PCBA Order
- Download and complete the BOM and centroid files using our templates.
- Include Gerber files with paste layer for SMT assemblies.
- Submit your files and credit application (if applicable).
- We review your files, confirm part sourcing or consignment details.
- Once approved, your order enters production. All assemblies are built to IPC-A-610 standards.
- Receive fully inspected assemblies with complete traceability and documentation.
- For wire harnesses, submit drawings or specs and we’ll walk you through material options, tooling, and quoting.
Supplying Your Own Parts?
If you’re providing components, please:
-
Clearly label all parts by reference designator and part number. -
Provide reels, cut tape, or trays for SMT components — and include a minimum 15% overage to account for mis-picks, feeder setup, and placement rejections during automated assembly. Bulk packaging may incur additional handling fees.
-
Include a functional sample if available, especially for complex builds.
Warranty & Quality Commitment
All PCB/PCBA assemblies are backed by a 90-day workmanship warranty. If we designed and assembled your product, you’re also covered by a 1-year warranty.
To request an RMA, contact us at
accounting@JourneyElectronics.com
or call (513) 539‑9836
Frequently Asked Questions (FAQ)
- Can I provide my own components?
- Yes — just ensure they’re labeled by reference designator and supplied in reels, tape, or trays where possible.
- Do you accept both turnkey and consignment jobs?
- Absolutely. We offer full turnkey PCB/PCBA services or can build using parts you provide.
- What file formats do you need?
- We recommend Gerber files (RS-274X), an Excel BOM, and a centroid/PNP file for assembly.
- Can I submit a wire harness project through this page?
- Yes — just include drawings or call us directly to review your requirements before quoting.
